Forklift Starter - Today's starter motor is typically a permanent-magnet composition or a series-parallel wound direct current electrical motor with a starter solenoid installed on it. Once current from the starting battery is applied to the solenoid, mainly through a key-operated switch, the solenoid engages a lever which pushes out the drive pinion that is positioned on the driveshaft and meshes the pinion utilizing the starter ring gear that is seen on the flywheel of the engine.
As soon as the starter motor starts to turn, the solenoid closes the high-current contacts. When the engine has started, the solenoid has a key operated switch that opens the spring assembly in order to pull the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This allows the pinion to transmit drive in just a single direction. Drive is transmitted in this particular manner via the pinion to the flywheel ring gear. The pinion continuous to be engaged, for instance as the operator did not release the key when the engine starts or if the solenoid remains engaged for the reason that there is a short. This actually causes the pinion to spin independently of its driveshaft.
The actions mentioned above would stop the engine from driving the starter. This significant step prevents the starter from spinning very fast that it can fly apart. Unless modifications were done, the sprag clutch arrangement will stop utilizing the starter as a generator if it was used in the hybrid scheme mentioned earlier. Usually a regular starter motor is intended for intermittent utilization which would preclude it being utilized as a generator.
The electrical components are made so as to function for around thirty seconds to stop overheating. Overheating is caused by a slow dissipation of heat is because of ohmic losses. The electrical parts are designed to save weight and cost. This is actually the reason most owner's guidebooks for automobiles suggest the driver to stop for at least 10 seconds after each and every ten or fifteen seconds of cranking the engine, when trying to start an engine that does not turn over instantly.
The overrunning-clutch pinion was introduced onto the marked during the early part of the 1960's. Previous to the 1960's, a Bendix drive was utilized. This drive system functions on a helically cut driveshaft that consists of a starter drive pinion placed on it. Once the starter motor starts turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. Once the engine starts, the backdrive caused from the ring gear enables the pinion to exceed the rotating speed of the starter. At this point, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.
In the 1930s, an intermediate development between the Bendix drive was developed. The overrunning-clutch design that was made and introduced in the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism together with a set of flyweights in the body of the drive unit. This was better because the standard Bendix drive used to disengage from the ring when the engine fired, even if it did not stay running.
As soon as the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, like for example it is backdriven by the running engine, and then the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement can be prevented before a successful engine start.
